GENERAL INFORMATION 1-5
Items LV1000-A1
Final drive system:
Type Chain drive
Reduction ratio 2.411 (41/17)
Overall drive ratio 4.045 @Top gear
Frame:
Type Tubular, diamond
Caster (rake angel)
26q 30c
Trail 111 mm (4.4 in.)
Front tire:
Type Tubeless
Size 110/80 R19 M/C 59H
Rear tire:
Type Tubeless
Size 150/70 R17 M/C 69H
Front suspension:
Type Telescopic fork
Wheel travel 160 mm (6.3 in.)
Rear suspension:
Type Swingarm
Wheel travel 159 mm (6.3 in.)
Brake type:
Front Dual discs
Rear Single disc
Electrical Equipment:
Battery 12 V 10 Ah
Headlight
12 V 60/55W u 2 (H4 u 2)
Tail/brake light
12 V 21/5W u 2
Alternator:
Type Three-phase AC
Specifications are subject to change without notice, and may not apply to every country.
