6-14 CHASSIS
FRONT FORK
CONSTRUCTION
ITEM N·m kgf-m lb-ft
23 2.3 16.5
20 2.0 14.5
23 2.3 16.5
20 2.0 14.5
O-ring
Washer
Spacer
Spring
Inner rod/damper rod (cartridge)
Inner tube
Slide metal
Gasket
Dust seal
Oil seal stopper ring
Oil seal
Oil seal retainer
Guide metal
Oil lock piece
Outer tube
Front fork cap bolt
Inner rod lock nut
Front axle pinch bolt
Damper rod bolt
