SERVICING INFORMATION 8-3
Base Manual Tools
Kawasaki Recommend tools
09900-20701
Magnetic stand
A suitable
commercially available
magnetic stand
09900-20803
09900-20806
Thickness gauge
A suitable
commercially available
thickness gauge
09900-20805
Tire depth gauge
A suitable
commercially available
tire depth gauge
09900-21304
V-block set (100 mm)
A suitable
commercially available
V-block set (100 mm)
09900-22301
09900-22302
Plastigauge
A suitable
commercially available
plastigage (0.025 ~
0.076 mm)
Base Manual Tools
Kawasaki Recommend tools
09900-22403
Small bore gauge
(18 ~ 35 mm)
A suitable
commercially available
small bore gauge (18 ~
35 mm)
09900-25008
Multi circuit tester set
A suitable
commercially available
digital multi meter for a
diode tester, peak
voltage adapter (Kowa
Seiki KEK-54-9-B) and
tachometer
09910-10750
Compression gauge
adapter
57001-1317
Compression gauge
adapter, M10 1.0
09913-13121
Carburetor balancer
set
57001-1369
Digital vacuum gauge
09913-50121
Oil seal remover
A suitable
commercially available
tool
