GENERAL INFORMATION 1-7
INFORMATION LABELS
Noise label (For E-03, 24, 33)
Information label (For E-03, 28, 33)
ICES Canada label (For E-28)
Vacuum hose routing label (For E-33)
Fuel caution label (For E-02, 24)
Manual notice label (For E-03, 33)
Tire pressure label
Warning safety label
Rear carrier warning label
Frame caution label
Steering warning label
Screen warning label
ID label (For E-02, 19, 24)
Safety label (For E-03, 28, 33)
For E-28 (French)
For E-28
These labels are attached
on the right frame.
