SERVICING INFORMATION 8-21
CRANKCASE BREATHER HOSE ROUTING
right down side.
right side.
: The end of the clamp should face.....
: The clamp screw head should face.....
rear side.
Water hose
Air cleaner box
Crankcase breather hose
(PCV hose)
