DGS-3312SR Stackable Gigabit Layer 3 Switch
MAC Notification
ion Global Settings
MAC address notification is used to monitor MAC addresses as they are learned and entered into the Switch’s MAC
forwarding database.
MAC Notificat
The following window will allow the user to globally enable MAC Notification on the Switch. To view this window, click
Configuration > MAC Notification > MAC Notification Global Settings.
ndow
The following parameters can be set:
Figure 4- 63. MAC Notification Global Settings wi
Parameter Description
State
This drop-down menu is used to enable or disable MAC notification on the selected
Switch.
Interval (sec)
The time in seconds between notifications.
History size
the History log. Up to 500 entries
can be specified.
The maximum number of entries that will be listed in
Click Apply to implement changes made.
