DGS-3312SR Stackable Gigabit Layer 3 Switch

To download certificates, set the following parameters and click Apply.

Parameter Description

Server IP

Enter the IP address of the TFTP server where the certificate files are located.

Certificate File Name

Enter the path and the filename of the certificate file to download. This file must have

a .der extension. (Ex. c:/cert.der)

Key File Name

Enter the path and the filename of the key file you wish to download. This file must

have a .der extension (Ex. c:/pkey.der)

Configuration

This window will allow the user to enable SSL on the Switch and implement any one or combination of listed ciphersuites

on the Switch. A ciphersuite is a security string that determines the exact cryptographic parameters, specific encryption

algorithms and key sizes to be used for an authentication session. The Switch possesses four possible ciphersuites for the

SSL function, which are all enabled by default. To utilize a particular ciphersuite, disable the unwanted ciphersuites,

leaving the desired one for authentication. When the SSL function has been enabled, the web will become disabled. To

manage the Switch through the web based management while utilizing the SSL function, the web browser must support

SSL encryption and the header of the URL must begin with https://. (Ex. https://10.90.90.90) Any other method will result

in an error and no access can be authorized for the web-based management.

To view the following window, click Security > Secure Socket Layer (SSL) > Configuration:

Figure 6- 3. SSL Configuration window

To set up the SSL function on the Switch, configure the following parameters and click Apply.

Parameter Description

RSA with RC4 128

MD5

e combines the RSA key exchange, stream cipher RC4 encryption with This ciphersuit

128-bit keys and the MD5 Hash Algorithm. Use the pull-down menu to enable or

disable this ciphersuite. This field is Enabled by default.

RSA with 3DES EDE

CBC SHA

ipher 3DES_EDE

encryption and the SHA Hash Algorithm. Use the pull-down menu to enable or disable

This ciphersuite combines the RSA key exchange, CBC Block C

this ciphersuite. This field is Enabled by default.

DHE DSS with 3DES

EDE CBC SHA

hersuite combines the DSA Diffie Hellman key exchange, CBC Block Cipher

3DES_EDE encryption and SHA Hash Algorithm. Use the pull-down menu to enable

This cip

or disable this ciphersuite. This field is Enabled by default.

177
