DGS-3312SR Stackable Gigabit Layer 3 Switch

Initializing Ports for Port-Based 802.1x

s Entity > PAE System Control > Initialize Port(s) to open the following window:

Existing 802.1x port and MAC settings are displayed and can be configured using the window below.

Click Configuration > Port Acces

Figure 4- 23. Initalize Port window for Port-Based 802.1x

This window allows you to i bottom half of the window

displays the current status of t

nitialize a port or group of ports. The Initialize Port Table in the

he port(s).

This window displays the following information:

Parameter Description

Unit

Choose the Switch ID number of the Switch in the Switch stack to be modified.

From and To

Select ports to be initialized.

Port

A read only field indicating a port on the Switch.

MAC Address

The MAC address of the Switch connected to the corresponding port, if any.

Auth PAE State

ay one of the following: Initialize, Discon-

uth,

The Authenticator PAE State will displ

nected, Connecting, Authenticating, Authenticated, Aborting, Held, ForceA

ForceUnauth, and N/A.

Backend State

ne of the following: Request,

N/A.

The Backend Authentication State will display o

Response, Success, Fail, Timeout, Idle, Initialize, and

Port Status

The status of the controlled port can be Authorized, Unauthorized, or N/A.
