Layer 3 Feature
ring windows are described below.
Traceroute
The foll will aid the user in back tracing the route taken by a packet before arriving at the Switch. When
initiated ogram will display the IP addresses of the previous hops a packet takes from the Target IP
Address dow, until it reaches the Switch.
The Switch’s Layer 3 monito
owing window
, the Traceroute pr
entered in the win
Figure 8- 25. Traceroute window
To trace the route of a packet, set the following parameters located in this window, and click Start.
Parameter Description
Target IP Address
Enter the IP address of the computer to be traced.
TTL
The time to live value of the trace route request. This is the maximum number of
d will cross while seeking the network path between routers the traceroute comman
two devices.
Port
The virtual port number. The port number must be above 1024.The value range is
from 30000 to 64900.
Timeout
Defines the time-out period while waiting for a response from the remote device.
The user may choose an entry between 1 and 65535 seconds.
Probe
The probe value is the number of times the Switch will send probe packets to the
next hop on the intended traceroute path. The default is 1.
