DGS-3312SR Stackable Gigabit Layer 3 Switch

Subnet Mask

A Bitmask that determines the extent of the subnet that the Switch is on. Should be of

the form xxx.xxx.xxx.xxx, where each xxx is a number (represented in decimal) between

5.255.255.0 for a Class C network, but custom subnet masks

0 and 255. The value should be 255.0.0.0 for a Class A network, 255.255.0.0 for a

Class B network, and 25

are allowed.

Default Gateway

IP address that determines where packets with a destination address outside the

current subnet should be sent. This is usually the address of a router or a host acting as

an IP gateway. If your network is not part of an intranet, or you do not want the Switch

to be accessible outside your local network, you can leave this field unchanged.

VID

This allows the entry of a VLAN ID from which a management station will be allowed to

using IP (in-band via web manager or Telnet). Management

entered in the VID field will not be able to

an ess their IP addresses are entered in the Security IP

configured for the Switch, the default

VID (1) contains all of the Switch’s ports. There are no entries in the Security IP

Management table, by default − so any management station that can connect to the

Switch can access the Switch until either Management Station IP Addresses (see page

29) are assigned or SNMP settings are configured to control management.

manage the Switch

stations that are on VLANs other than the one

TCP/

manage the Switch in-b

Management menu. If VLANs have not yet been

d unl

Setting the Switch’s IP A ss using the Co le Interface

assigned its own IP Address, hich is used for comm cation with an SNMP network

manager or other TCP/IP applicat witch’s default IP address is

10.90.90.90. You can change the ation of your networking address

The IP address for the Switch must be set before it can be managed with the Web-based manager. The Switch IP

address can be automatically set using BOOTP or DHCP protocols, in which case the actual address assigned to

the Switch must be known.

The IP address may be set using the Command Line Interface (CLI) over the console serial port as follows:

Starting at the command line prompt, enter the commands config ipif System ipaddress

xxx.xxx.xxx.xxx/yyy.yyy.yyy.yyy. Where the x’s represent the IP address to be assigned to the IP interface

named System and the y’s represent the corresponding subnet mask.

Alternatively, you can enter config ipif System ipaddress xxx.xxx.xxx.xxx/z. Where the x’s represent the IP

address to be assigned to the IP interface named System and the z represents the corresponding number of

subnets in CIDR notation.

The IP interface named System on the Switch can be assigned an IP address and subnet mask that can then be

used to connect a management station to the Switch’s Telnet or Web-based management agent.

The system message Success indicates that the command was executed successfully. The Switch can now be

configured and managed via Telnet and the CLI or via the Web-based management agent using the above IP

address to connect to the Switch.

ddre nso

Each Switch must be w uni

ion (for example BOOTP, TFTP). The S

default Switch IP address to meet the specific

scheme.
