DGS-3312SR Stackable Gigabit Layer 3 Switch

SNMP Host Table

Use the SNMP Host Table to set up SNMP trap recipients.

Open the SNMP Manager folder, located in the Management folder, and click on the SNMP H

open the SNMP Host Table page, as shown below.

ost Table link. This will

To delete an existing SNMP Host Table entry, click the corresponding

under the Delete heading.

To display the current settings for an existing SNMP Group Table entry, click the blue link for the entry under the Host

IP Address heading.

Figure 7- 14. SNMP Host Table window

To add a new entry to the Switch’s SNMP Group Table, click the Add button in the upper left-hand corner of the SNMP

Host Table window. This will open the SNMP Host Table Configuration window, as shown below.

Figure 7- 15. SNMP Host Table Configuration window

t: The following parameters can se

Parameter Description

Host IP Address

Type the IP address of the remote management station that will serve as the SN

host for the Switch.

SNMP Version

V1 - To specifies that SNMP version 1 will be used.

V2 - To specify that SNMP version 2 will be used.

pecify that the SNMP version 3 will be used, with a

NoAuth-NoPriv security level.

V3-Auth-NoPriv - To specify that the SNMP version 3 will be used, with an Auth-

NoPriv security level.

V3-Auth-Priv - To specify that the SNMP version 3 will be used, with an Auth-Priv

security level.

V3-NoAuth-NoPriv - To s

Community String or

SNMP V3 User Name

Type in the community string or SNMP V3 user name as appropriate.

Click Apply to implement changes made.
