or OSPF, the Switch must first be globally enabled for Layer 3 IP Networking. To

bal Advanced Settings

F for the Switch, select Enabled using the pull-down menu for the global setting

and click the Apply button. You may later select Disabled for any of these to disable the protocol without changing any of

t may have b

MD5 Key Settings

L3 Global Advanced Settings

In order to use DVMRP, PIM-DM, RIP,

enable or disable these Layer 3 protocols as well as configure ARP Aging Time, access the L3 Glo

window by clicking Configuration > Layer 3 IP Networking > L3 Global Advanced Settings.

To enable DVMRP, PIM-DM, RIP or OSP

he settings that een configured for them.

The user may globally set t mum amount of time, in minutes, which an Address Resolution Protocol (ARP) entry

can remain in the Switch’s ARP table, without being accessed, before it is dropped from the table. The value may be set in

fault setting of 20 minutes.

Figure 5- 1. L3 Global Advanced Settings window

he maxi

the range of 0-65535 minutes with a de

NOTE: PIM, RIP, OSPF, and DVMRP may also be globally enabled or disabled

using a separate global settings window for each protocol. The links for the

individual global settings windows are located in their respective subfolders.
