Shortest Path Tree
To bui er A’s shortest path tree for iagramed below, Router A is put at the root of the tree and the
smallest cost link to each destination network is calculated.
ld Rout the network d
Figure 5- 16. Constructing a Shortest Path Tree
Router A
Router B
128.213.0.0
Router C
Router D
192.213.11.0
0
5
10
10
222.211.10.0
5
10
10
5- 17. Constructing a Shortest Path Tree Figure
The diagram above shows the network from the viewpoint of Router A. Router A can reach 192.213.11.0 through Router B
er D with a cost of 10+5+10=25, but the cost is higher than the route
through Router C. This higher-cost route will not be included in the Router A’s shortest path tree. The resulting tree will
look like this:
with a cost of 10+5=15. Router A can reach 222.211.10.0 through Router C with a cost of 10+10=20. Router A can also
reach 222.211.10.0 through Router B and Rout
133
