OSPF Virtual Interface Settings
r the configuration being removed.
Click the OSPF Virtual Interface Settings link to view the current OSPF virtual interface settings. There are not virtual
interface settings configured by default, so the first time this table is viewed there will be not interfaces listed. To add a
new OSPF virtual interface configuration set to the table, click the Add button. A new window appears (see below). To
change an existing configuration, click on the hyperlinked Transit Area ID for the set you want to change. The window to
modify an existing set is the same as the window used to add a new one. To eliminate an existing configuration, click the X
in the Delete column fo
Figure 5- 35. OSPF Virtual Interface Settings window
The status of the virtual interface appears (Up or Down) in the Status column.
Figure 5- 36. OSPF Virtual Interface Settings – Add window
eters if you are adding or changing an OSPF Virtual Interface: Configure the following param
Parameter Description
Transit Area ID
Allows th previously defined on the Switch that allows
a remot
Stub Area or a Backbone Area.
e entry of an OSPF Area ID
e area to communicate with the backbone (area 0). A Transit Area cannot be a
N
e OS
address (xxx.xxx.xxx.xxx) that uniquely identifies the remote area’s Area Border
Router.
eighbor Router
Th PF router ID for the remote router. This is a 32-bit number in the form of an IP
153
