DGS-3312SR Stackable Gigabit Layer 3 Switch
SNMP View Table
The SNMP View Table is used to assign views to community strings that define which MIB objects can be accessed by a
remote SNMP manager. To view the SNMP View Table, open th
er, an
e SNMP Manager folder, located in the Management
fold d click the SNMP View Table entry. The following screen should appear:
Figure 7- 8. SNMP View Table window
To delete an existing SNMP View Table entry, click the X button listed under Delete on the far left that corresponds to
View Name. To create a new entry, click the Add button, a separate window will appear.
Figure 7- 9. SNMP View Table Configuration window
The SNMP Group created with this table maps SNMP users (identified in the SNMP User Table window) to the views
created in the previous window.
The following parameters can set:
Parameter Description
View Name
Type an alphanumeric string of up to 32 characters. This is used to identify the new
SNMP view being created.
Subtree OID
Type the Object Identifier (OID
(MIB tree) that will be included or excluded from access by an SNMP manager.
) Subtree for the view. The OID identifies an object tree
Vie
cluded to include this object in the list of objects that an SNMP manager can
ct Excluded to exclude this object from the list of objects that an SNMP
w Type
Select In
access. Sele
manager can access.
203
