DGS-3312SR Stackable Gigabit Layer 3 Switch

Figure 2-10. Assigning the Switch an IP Address

assigned an IP address of 10.22.24.9 with a subnet mask of 255.0.0.0. The system

Connecting Devices to the Switch

After you assign IP addresses to the Switch, you can connect devices to the Switch.

To connect a device to an SFP transceiver port:

1. Use your cabling requirements to select an appropriate SFP transceiver type.

2. Insert the SFP transceiver (sold separately) into the SFP transceiver slot.

3. Use the appropriate network cabling to connect a device to the connectors on the SFP transceiver.

In the above example, the Switch was

message Success indicates that the command was executed successfully. The Switch can now be configured and managed

via Telnet and the CLI or via the Web-based management.

NOTICE: When the SFP transceiver acquires a link, the associated integrated

10/100/1000BASE-T port is disabled.
