DGS-3312SR Stackable Gigabit Layer 3 Switch
DHCP/BOOTP Re
The DHCP/ BOOTP Rela ings allow the user to set up a server, by IP address, for relaying DHCP/
BOOTP information to the
connected directly to the DH
in the BOOTP Relay Table ly
heading. The user may add by clicking it’s
corresponding X.
lay Settings
y Interface Sett
Switch. The user may enter a previously configured IP interface on the Switch that will be
CP/BOOTP server using the following window. Properly configured settings will be displayed
at the bottom of the following window, once the user clicks the Add button under the App
up to four server IPs per IP interface on the Switch. Entries may be deleted
Figure 5- 42. DHCP/BOOTP Relay Settings window
To create a new relay configuration, enter the IP interface name you want to configure for DHCP relay and the IP address
of the server. Click on the Add button to enter the relay settings. Up to four servers can be entered for each IP interface.
The information listed in the window is described as follows:
Parameter Description
Interface
The IP interface on the Switch that will be connected directly to the Server.
Server IP
Enter the IP address of the DHCP/BOOTP server. Up to four server IPs can be
configured per IP Interface
158
