DGS-3312SR Stackable Gigabit Layer 3 Switch
Advanced Settings
To view the following window, click Configuration > Advanced Settings:
Figure 3- 11. Switch Information (Advanced Settings) window
The Advanced Settings options are summarized in the table below:
Parameter Description
Serial Port Auto
Logout
Select the logout time used for the console interface. This automatically logs the
he following options: 2 user out after an idle period of time as defined. Choose from t
Minutes, 5 Minutes, 10 Minutes, 15 Minutes or Never.
Serial Port Baud Rate
Select the baud rate used for the console interface. This automatically logs the user
9600,
, 38400 or 115200.
out after an idle period of time as defined. Choose from the following options:
19200
MAC Address Aging
This field specifies the length of time a learned
Tim
MAC Address will remain in the
ed (that is, how long a learned MAC Address
age-out time for the Switch is 300 seconds.
ting the MAC address age-out time
1,000,000
e (10-1000000)
forwarding table without being access
is allowed to remain idle). The default
To change this, type in a different value represen
in seconds. The Aging Time can be set to any value between 10 and
seconds.
IGMP Snooping
To enable system-wide IGMP Snooping capability select Enabled. IGMP snooping
is Disabled by default. Enabling IGMP snooping allows you to specify use of a
P Snooping for individual
P folder.
multicast router only (see below). To configure IGM
VLANs, use the IGMP Snooping window in the IGM
33
