DGS-3312SR Stackable Gigabit Layer 3 Switch
Multicast router Only
If this option is enabled and IGMP Snooping is also enabled, the Switch forwards all
, the Switch will
cast traffic to any IP router.
multicast traffic to a multicast-enabled router only. Otherwise
forward all multi
Telnet Stat
Telnet confi
us
guration is Enabled by default. If you do not want to allow configuration
of the system through Telnet choose Disabled.
Telnet TCP Port
Number (1-65535)
lnet TCP port number. TCP ports are numbered between 1 and 65535. The
"well-known" TCP port for the Telnet protocol is 23.
The Te
Web Status
Web-based management is Enabled by default. If you choose to disable this by
web selecting Disabled, you will lose the ability to configure the system through the
interface as soon as these settings are applied.
Web TCP Port
Number (1-65535)
b The TCP port number currently being utilized by the Switch to connect to the we
interface. The "well-known" TCP port for the Web interface is 80.
RMON Status
or Disabled here. Remote monitoring (RMON) of the Switch is Enabled
GVRP
Use this pull-down menu to enable or disable GVRP on the Switch.
Link Aggreg
Algorithm
ation
e ports that make
Source, MAC
The algorithm that the Switch uses to balance the load across th
up the port trunk group is defined by this definition. Choose MAC
Destination, MAC Src & Dest, IP Source, IP Destination, and IP Src & Dest. (See
Link Aggregation)
Switch 802.1x
The Switch’s 802.1x function may be enabled by port or by MAC Address; the
default is Disabled. This field must be enabled to view and configure certain
windows for 802.1x. More information regarding 802.1x, its functions and
implementation can be found later in this section, under the Port Access Entity
folder.
Port-Based 802.1x specifies that ports configured for 802.1x are initialized based
on the port number only and are subject to any authorization parameters
configured.
MAC-based 802.1x specifies that ports configured for 802.1x are initialized based
on the port number and the MAC address of the computer being authorized and are
then subject to any authorization parameters configured.
Syslog state
Use this pull-down menu to enable or disable Syslog.
Click Apply to implement changes made.
34
