DGS-3312SR Stackable Gigabit Layer 3 Switch
Reauthenticate P
his window allows you to ticate a port or group of ports by choosing a port or group of ports by using the pull
down menus From and To and clicking Apply. The Reauthenticate Port Table displays the current status of the
ce
lick Configuration > P
win
ort(s) for Port Based 802.1x
reauthenT
reauthenticated port(s) on you have clicked Apply.
ort Access Entity > PAE System Control > Reauthenticate Port(s) to open the
dow:
C
Reauthenticate Port(s)
Figure 4- 25. Reauthenticate Port and Reauthenticate Port Table w
This window displays the following information:
indow
Parameter Description
Unit
Choose the Switch ID number of the Switch in the Switch stack to be modified.
Port
The port number of the reauthenticated port.
MAC Address
Displays the physical address of the Switch where the port resides.
Auth PAE State
The Authenticator State will display one of the following: Initialize, Disconnected,
Connecting, Authenticating, Authenticated, Aborting, Held, ForceAuth, ForceUnauth,
and N/A.
BackendState
The Backend State will display one of the following: Request, Response, Success, Fail,
Timeout, Idle, Initialize, and N/A.
PortStatus
The status of the controlled port can be Authorized, Unauthorized, or N/A.
63
