DGS-3312SR Stackable Gigabit Layer 3 Switch
CPU Utilization
e CPU.
To v , click on the Monitoring folder and then the CPU Utilization link:
This CPU Utilization window displays the moving average of th
iew the CPU utilization
Figure 8- 5. CPU Utilization window
The following field can be set:
Parameter Description
Time Interval <1s>
Selec ” stands for seconds. The t the desired setting between 1s and 60s, where “s
default value is one second.
Record Number
Select number of times the Switch will
<200>
value is 200.
be polled between 20 and 200. The default
Show/Hide
Check to disp
lay Utilization.
214
