DGS-3312SR Stackable Gigabit Layer 3 Switch

Brows SP

OSPF Monitor folder by clicking on the Browse OSPF Virtual Neighbor Table link. This

table dis itch. The user may choose specifically search a virtual neighbor by

using on

e O F Virtual Neighbor Table

This table can be found in the

plays a list of Virtual OSPF neighbors of the Sw

e of the two search options at the top of the window:

Figure 8- 33. OSPF Virtual Neighbor Table window

Parameter Description

Transit Area ID

Allows the entry of an OSPF Area ID − previously defined on the Switch − that allows

a remote area to communicate with the backbone (area 0). A Transit Area cannot be

a Stub Area or a Backbone Area.

Neighbor ID

The OSPF router ID for the remote router. This IP address uniquely identifies the

remote area’s Area Border Router.

241
