DGS-3312SR Stackable Gigabit Layer 3 Switch
Appendix A
Technical Specifications
General
Standard
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.1 P/Q VLAN
IEEE 802.3x Full-duplex Flow Control
IEEE 802.3 Nway auto-negotiation
Protocols
CSMA/CD
Data Transfer Rates:
Ethernet
Half-duplex Full-duplex
10 Mbps 20Mbps
Fast Ethernet
Fiber Optic
100Mbps 200Mbps
IEC 793-2:1992
Type A1b - 62.5/125um multimode
Gigabit Ethernet
N/A 2000Mbps
Type A1a - 50/125um multimode
Both types use LC optical connector
Topology
Star
Network Cables
UTP Cat. 5 for 100Mbps
UTP Cat. 3, 4, 5 for 10Mbps
EIA/TIA-568 100-ohm screened twisted-pair (STP)(100m)
Performance
Transmission Method:
Store-and-forward
R M Buffer:
1 MB per device
A
Filtering Address
Table:
16 K MAC address per device
Packet Filtering/
Forwarding Rate:
Full-wire speed for all connections.
148,800 pps per port (for 100Mbps)
1,488,000 pps per port (for 1000Mbps)
263
