DGS-3312SR Stackable Gigabit Layer 3 Switch
MAC Address
Learning:
Automatic update.
Forwarding Table Age
Time:
Max age: 10 - 1000000 seconds.
Default = 300.
Physical & Environmental
AC inputs:
100 - 240 VAC, 50/60 Hz (internal universal power supply)
Power Consumption:
30 watts maximum
DC fans:
1 built-in 75 x 75 x30 mm fan
Operating
Temperature:
0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit)
Storage Temperature:
-25 to 55 degrees Celsius (-13 to 131 degrees Fahrenheit)
Humidity:
Operating: 5% to 95% RH, non-condensing
Storage: 0% to 95% RH, non-condensing
Dimensions:
441 mm x 309 mm x 44 mm (17.36 x 12.16 x 1.73 inches), 1UHeight, 19 inch rack-
mount width
Weight:
4.4 kg (9.7 lbs.)
EMI:
FCC Class A, CE Mark, C-Tick
Safety:
CSA International
264
