DGS-3312SR Stackable Gigabit Layer 3 Switch
Figure 7- 7. SNMP User Table Configuration window
The follo t: wing parameters can se
Parame ion ter Descript
User Name
Enter an alphanumeric string of up to 32 characters. This is used to identify the SNMP
user.
Group Name
This name is used to specify the SNMP group created can request SNMP messages.
SNMP V
- Specifies that SNMP version 1 will be used.
Specifies that SNMP version 2 will be used.
SNMP version 3 will be used.
ersion
V1
V2 -
V3 - Specifies that
Auth-Protocol
that the HMAC-MD5-96 authentication level will be used. This field is
le when V3 is selected in the SNMP Version field and the Encryption
will require the user to enter a password.
the HMAC-SHA authentication protocol will be used. This field is
V3 is selected in the SNMP Version field and the Encryption
s been checked. This field will require the user to enter a password.
MD5 - Specifies
only operab
field has been checked. This field
SHA - Specifies that
only operable when
field ha
Priv-Protocol
pecifies that no authorization protocol is in use.
- Specifies that DES 56-bit encryption is in use, based on the CBC-DES (DES-
56) standard. This field is only operable when V3 is selected in the SNMP Version
None - S
DES
field and the Encryption field has been checked. This field will require the user to
enter a password between 8 and 16 alphanumeric characters.
Click Apply to implement changes made.
202
