DGS-3312SR Stackable Gigabit Layer 3 Switch
Access ID
Type in a unique identifier number for this access. This value can be set from 1 to
255.
Type
Selected profile based on Ethernet (MAC Address), IP address or packet content
for the type of profile.
ts the Switch to examine the layer 2 part of each packet
Content Mask specifies a mask to hide the content of the packet
header.
mask. This will change the menu according to the requirements
• Ethernet instruc
header.
• IP instructs the Switch to examine the IP address in each frame’s header.
• Packet
Priority (0-7)
you want to re-write the 802.1p default priority previously
Replace priority − Click the corresponding box if you want to re-write the 802.1p
the
d
ser priority re-written
to its original value before being forwarded by the Switch.
For more information on priority queues, CoS queues and mapping for 802.1p, see
the QoS section of this manual.
This parameter is specified if
set in the Switch, which is used to determine the CoS queue to which packets are
forwarded to. Once this field is specified, packets accepted by the Switch that match
this priority are forwarded to the CoS queue specified previously by the user.
default priority of a packet to the value entered in the Priority field, which meets
criteria specified previously in this command, before forwarding it on to the specifie
CoS queue. Otherwise, a packet will have its incoming 802.1p u
Offset
This field will instruct the Switch to match the packet header beginning with the offset
value specified:
• value (0-15) - Enter a value in hex form to mask the packet from the
beginning of the packet to the 15th byte.
• value (16-31) - Enter a value in hex form to mask the packet from byte 16 to
byte 31.
• value (32-47) - Enter a value in hex form to mask the packet from byte 32 to
byte 47.
• value (48-63) - Enter a value in hex form to mask the packet from byte 48 to
byte 63.
• value (64-79) - Enter a value in hex form to mask the packet from byte 64 to
byte 79.
Click Apply to implement changes made.
119
