DGS-3312SR Stackable Gigabit Layer 3 Switch
Configure the Access Rule Configuration settings for the Packet Content Mask on the window below.
Figure 4- 79. Access Rule Configuration (Package Content Mask) window
The following parameters can be set:
Parameter Description
Profile ID
This is the identifier number for this profile set.
Mode
Select Permit to specify that the packets that match the access profile are forwarded
by the Switch, according to any additional rule added (see below).
Se ccess profile are not
forwarded by the Switch and will be filtered.
lect Deny to specify that packets that do not match the a
118
