DGS-3312SR Stackable Gigabit Layer 3 Switch
Parameter Description
Interface Name
n which RIP is to be setup. This interface must be
d on the Switch.
The name of the IP interface o
previously configure
The IP address corresponding to the
IP Address
Interface Name showing in the field above.
TX Mode
Toggle among Disabled, V1 Only, V1 Compatible, and V2 Only. This entry specifies
which version of the RIP protocol will be used to transmit RIP packets. Disabled
prevents the transmission of RIP packets.
RX Mode
Toggle among Disabled, V1 Only, V2 Only, and V1 or V2. This entry specifies which
version of the RIP protocol will be used to interpret received RIP packets. Disabled
prevents the reception of RIP packets.
Authentication
Toggle between Disabled and Enabled to specify that routers on the network should
us the Password above to authenticate router table exchanges.
Password
A password to be used to authenticate communication between routers on the
network.
State
Toggle between Disabled and Enabled to disable or enable this RIP interface on the
Switch.
Interface Metric
A read only field that denotes the Metric value of the current IP Interface setting.
Click Apply to implement changes made.
131
