DGS-3312SR Stackable Gigabit Layer 3 Switch

To add an OSPF Area to the table, type a u

Stub type, choose Enabled or Disabled from

nique Area ID (see below) select the Type from the drop-down menu. For a

the Stub Import Summary LSA drop-down menu and determine the Stub

Default Cost. Click the Add/Modify button to add the Area ID set to the table.

To remove an Area ID configuration set, simply click the X in the Delete column for the configuration

To change an existing set in the list, type the Area ID of the set you want to change, make the changes and click the

Add/Modify button. The modified OSPF Area ID will appear in the table.

Figure 5- 32. OSPF Area Settings window

See the parameter descriptions below for information on the OSPF Area ID setting.

The Area ID settings are as follows:

Parameter Description

Area ID

A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely identifies

the OSPF area in the OSPF domain.

Type

This field can be toggled be

toggled to Stub, additional fields ap

tween Normal and Stub using the space bar. When it is

pear − Stub Import Summary LSA, and the Stub

Default Cost.

Stub Import

Summary LSA

D ed Area will allow Summary Link-State

Advertisements (Summary LSAs) to be imported into the area from other areas.

isplays whether or not the select

Stub Default Cost

Displays the default cost for the route to the stub of between 0 and 65,535. The default

is 1.
