DGS-3312SR Stackable Gigabit Layer 3 Switch

Figure 5- 53. DVMRP Interface Settings window - Modify

Configure DVMRP settings for each IP interface and click on the Apply button to apply the new or changed settings. The

new values will appear in the DVMRP Interface Settings table in the previous window. To view the table click

Show All

DVMRP Interface Entries.

The table below describes the parameters necessary for DVMRP configuration.

Configure these settings for each DVMRP interface:

Parameter Description

Interface Name

Displays the name of the IP interface for which DVMRP is to be configured. This must

be a previously defined IP interface.

IP Address

Displays the IP address corresponding to the IP Interface name entered above.

Neighbor Timeout

Interval (1-65535)

This field allows an entry between 1 and 65,535 seconds and defines the time period

DVMRP will hold Neighbor Router reports before issuing poison route messages. The

default is 35 seconds.

Probe Interval (1-

65535)

This field allows an entry between 1 and 65,535 seconds and defines the interval

between ‘probes’. The default is 10.

Metric (1-31)

This field allows an entry between 1 and 31 and defines the route cost for the IP

interface. The DVMRP route cost is a relative number that represents the real cost of

using this route in the construction of a multicast delivery tree. It is similar to, but not

defined as, the hop count in RIP. The default cost is 1.

State

This field can be toggled between Enabled and Disabled and enables or disables

DVMRP for the IP interface. The default is Disabled.

172
