DGS-3312SR Stackable Gigabit Layer 3 Switch
AES128-CBC
Use the pull-down menu to enable or disable the Advanced Encryption Standard
AES128 encryption algorithm with Cipher Block Chaining. The default is Enabled.
AES192-CBC
Use the pull-down menu to enable or disable the Advanced Encryption Standard
AES192 encryption algorithm with Cipher Block Chaining. The default is Enabled.
AES256-CBC
Use the pull-down menu to enable or disable the Advanced Encryption Standard
AES256 encryption algorithm with Cipher Block Chaining. The default is Enabled.
ARC4
Use the pull-down menu to enable or disable the Arcfour encryption algorithm. The
default is Enabled.
Cast128-CBC
Use the pull-down menu to enable or disable the Cast128 encryption algorithm with
Cipher Block Chaining. The default is Enabled.
Twofish128
Use the pull-down menu to enable or disable the twofish128 encryption algorithm. The
default is Enabled.
Twofish192
Use the pull-down menu to enable or disable the twofish192 encryption algorithm. The
default is Enabled.
Twofish256
Use the pull-down menu to enable or disable the twofish256 encryption algorithm. The
default is Enabled.
Data Integrity Algorithm
HMAC-SHA1
Use the pull-down menu to enable or disable the HMAC (Hash for Message
Authentication Code) mechanism utilizing the Secure Hash Algorithm encryption. The
default is Enabled.
HMAC-MD5
Use the pull-down menu to enable or disable the HMAC (Hash for Message
st encryption Authentication Code) mechanism utilizing the MD5 Message Dige
algorithm. The default is Enabled.
Public Key Algorithm
HMAC-RSA
Use the pull-down menu to enable or disable the HMAC (Hash for Message
Authentication Code) mechanism utilizing the RSA encryption algorithm. The default is
Enabled.
HMAC-DSA
Use the pull-down menu to enable or disable the HMAC (Hash for Message
Authentication Code) mechanism utilizing the Digital Signature Algorithm encryption.
The default is Enabled.
Authentication Algorithm
Password
This ly configured
s
parameter may be enabled if the administrator wishes to use a local
sword for authentication on the Switch. The default is Enabled. pa
Public Key
This parameter may be enabled if the administrator wishes to use a publickey
configuration set on a SSH server, for authentication. The default is Enabled.
Host-based
This computer for
auth
authentication techniques and the host computer is running the Linux operating
system with a SSH program previously installed. The default is Enabled.
parameter may be enabled if the administrator wishes to use a host
entication. This parameter is intended for Linux users requiring SSH
Click Apply to implement changes made.
182
