DGS-3312SR Stackable Gigabit Layer 3 Switch

1. Select Enable from

2. Select the Stack Port by clicking to check a corresponding selection box.

ck Information Tabl

order in the Sw NO.

heading. The Stack ID LED display on the front panel of the DGS-3312SR will always display an F (15 in hex), regardless

S-3312S

Below is an example of the Stack Mode Setup window with stacking mode enabled on Port 1.

the Stack Mode State drop-down menu.

The Sta e displays the read-only information listed in the table on the next page.

The current itch stack is also displayed on the front panel of each slave Switch, under the STACK

of whether the DG R is the master Switch in a Switch stack or in standalone mode.

Figure 8- 2. Stack Mode Setup (stacking enabled) window

Variables in this window are described below:

Parameter Description

Displays the Switch’s order in the stack. The Switch with a unit id of 1 is the master

Switch.

MAC Address

Displays the unique address of the Switch assigned by the factory.

Port Range

Displays the total number of ports on the Switch. Note that the stacking port is

included in the total count.

Mode

Displays the method used to determine the stacking order of the Switches in the

Switch stack.

Version

Displays the version number of the stacking firmware.

RPS Status

Displays the status of an optional Redundant Power Supply.

Model Name

Displays the model name of the corresponding Switch in a stack.

When the stacked group is connected and properly configured, the virtual stack appears in the upper right-hand corner of

the web page.

211
