DGS-3312SR Stackable Gigabit Layer 3 Switch
Figure 3- 13. Stack Mode Setup (stacking enabled) window
Variable s window are described below: s in thi
Parame escription ter D
ID
lays the Switch’s order in the stack. The Switch with a unit ID of 15 is the master
h.
Disp
Switc
MAC A
ys the unique address of the Switch assigned by the factory.
ddress
Displa
Port Range
s the total number of ports on the Switch. Note that the stacking port is
included in the total count.
Display
Mode
Displays the method used to determine the stacking order of the Switches in the
Switch stack.
Version
Displays the version number of the stacking firmware.
RPS Status
Displays the status of an optional Redundant Power Supply.
Model Name
Displays the model name of the corresponding Switch in a stack.
When the stacked group is connected and properly configured, the virtual stack appears in the upper right-hand corner of
the web page.
36
