DGS-3312SR Stackable Gigabit Layer 3 Switch

Parameter Description

Unit

This is the Unit ID of a Switch in a Switch stack. The number 15 indicates a DGS-

3312SR Switch in standalone mode.

From/To

A consecutive group of ports may be configured starting with the selected port.

Mode

Active – Active LACP ports are capable of processing and sending LACP control

frames. This allows LACP compliant devices to negotiate the aggregated link so the

group may be changed dynamically as needs require. In order to utilize the ability to

change an aggregated port group, that is, to add or subtract ports from the group, at

least one of the participating devices must designate LACP ports as active. Both

devices must support LACP.

Passive – LACP ports that are designated as passive cannot initially send LACP

control frames. In order to allow the linked port group to negotiate adjustments and

make changes dynamically, at one end of the connection must have “active” LACP

ports (see above).

After settin

shows whic

g the previous parameters, click Apply to allow your changes to be implemented. The LACP Port Mode Table

h ports are active and/or passive.
