GRAPHITE 59G801 [22/164] Operation and maintenance

SETTING THE TURNTABLE FOR MITRE CUTTING

The turntable (42) allows cutting material at any angle within range

of 45° left or right from the perpendicular position.

• Pull and turn the head locking pin (39) and allow the extension

arm to lift slowly to upper position.

• Loosen the table rotation locking knob (46).

• Press the turntable lock button (45) and set the turntable (42) at

desired angle. Use the angle scale of turntable (43) (g. K).

• Lock by tightening the table rotation locking knob (46).

There are many grooves in the turntable (42) that are used to easily

pick frequently used angles. Those are cutting angles that are used

most often (0°, 15°, 22.5°, 30°, 45° left or right). Any angle can be set

precisely with the use of the angle scale of turntable (43) scaled

every degree. Even though the scale is accurate enough for most

of performed tasks, it is recommended to double check the cutting

angle with protractor or other device for angle measurements.

When using standard angle quick setup, the pawl should clearly

sound snapping into the groove.

SETTING THE EXTENSION ARM (HEAD) FOR BEVEL CUTTING

Extension arm can be tilted left at any angle from the range of 0° to

45° (left) for bevel cutting (g. L).

• Pull the head locking pin (39) that releases the extension arm and

allow the extension arm to lift slowly to upper position.

• Loosen the head tilt locking lever (38).

• Tilt the extension arm left to desired angle that you can read on

the angular scale of head tilt (51) (g. M).

• Tighten the head tilt locking lever (38).

If you need to set both angles (in both planes, horizontal and

vertical) for compound cutting, always set the bevel angle rst.

CHECKING AND ADJUSTMENT OF PERPENDICULAR POSITION

OF CUTTING BLADE AND TURNTABLE

To guarantee precise cuts, check basic setup parameters of the saw

after some time of operation and readjust if necessary.

• Loosen the head tilt locking lever (38).

• Set the head in the extreme right position (perpendicular to the

turntable) and tighten the head tilt locking lever (38).

• Loosen the table rotation locking knob (46).

• Set the turntable (42) in 0° position and tighten the table rotation

locking knob (

46).

• Press the moving guard locking lever (32) and lower the saw head

to the extreme down position.

• Use the tool to check perpendicularity of cutting blade and the

turntable (42).

When making measurements make sure that measurement

device does not touch any cutting blade tooth, otherwise the

measurement may be inaccurate due to thickness of sintered

carbide insert.

In case the measurement angle is diﬀerent than 90

, the following

adjustment is necessary:

• Tilt the saw head to the left.

• Turn the adjustment screw (52) clockwise or counter-clockwise to

increase or reduce head tilt angle. Lock with the nut (53) (g. N).

• After perpendicular position of cutting blade and the turntable

has been set, allow the head to return to its upper position.

Carry out similar adjustment for 45

head bevel angle, using

adjustment screw (54) and the nut (55) located on the opposite side

of the extension arm (g. O).

OPERATION AND MAINTENANCE

Unplug the power cord from mains socket before commencing

any activities related to installation, adjustment, repair or

maintenance.

CLEANING

• When the work is ﬁnished, remove thoroughly all pieces of

material, shavings and dust from the work table, area around

cutting blade and its guard.

• Optimally clean the saw with brush or stream of compressed air

at low pressure.

• Never use water or other chemical liquids for cleaning the saw.

• Keep all handles and knobs clean.

• Clean ventilation holes regularly to prevent motor overheating.

• Store the saw in a dry place, beyond reach of children.

• Entrust replacement of power cord and other repairs only to

authorized service workshop.

Regularly check that all bolts and xing screws are tightened.

They may get loosened after some time of the operation.

CUTTING BLADE REPLACEMENT

Replace the cutting blade when the tool is set up in mitre saw

mode.

• Pull the head locking pin (39) to unlock the extension arm.

• Allow smooth return of the extension arm to upper position.

• Press and hold the moving guard locking lever (32).

• Shift the movable guard (33) up, undo the screw (56) and push

away the cover (57) (g. P), to access the ﬁxing bolt for cutting

blade (58) (g. R).

• Press and hold the spindle lock button (12) (turning the cutting

blade may be necessary to lock the spindle).

• Use the key and undo the ﬁxing bolt for cutting blade (58)

clockwise (left hand thread).

• Release the spindle lock button (12) and remove screw that ﬁxes

cutting blade and outer ﬂange (59).

• Clean all parts to be installed prior to installation.

• Put new cutting blade on, so it is pressed against surface of the

inner ﬂange and centred when seated on its neck.

• Position new cutting blade so blade teeth and arrow on the blade

match direction of the arrow on the guard.

• Put the outer ﬂange on, press and hold spindle lock button (12)

and tighten the cutting blade ﬁxing bolt counter-clockwise.

• Slide on the cover (57) and tighten the screw (56).

• Release the movable guard (33) to its default position (the guard

must fully cover the cutting blade).

• Ensure the movable guard (33) is in correct position and moves

freely when lifting or lowering the extension arm.

Be careful to keep appropriate direction of the cutting blade

rotation (see arrow on the cutting blade and stationary guard).

After cutting blade replacement make sure the blade is free to

move by turning it with your hand.

REPLACEMENT OF CARBON BRUSHES

Immediately replace worn out (shorter than 5 mm), burnt or

cracked motor carbon brushes. Always replace both carbon

brushes at a time.

Replace carbon brushes when the tool is set up in mitre saw mode.

• Unscrew carbon brush covers (60) (g. S).

• Remove worn out carbon brushes.

• Remove any carbon dust with stream of compressed air at low

pressure.
