DGS-3312SR Stackable Gigabit Layer 3 Switch
Figure 4- 34. STP Bridge Global Settings - MSTP
eters cThe following param an be set:
Parameter Description
STP Status
Use the pull-down menu to enable or disable STP globally on the Switch. The
default is Disabled.
STP Version
hoices:
lect this parameter to set the Spanning Tree Protocol (STP) globally on
tocol (RSTP)
globally on the Switch.
ing Tree Protocol (MSTP)
globally on the Switch.
Use the pull-down menu to choose the desired version of STP to be implemented
on the Switch. There are three c
STP - Se
the Switch.
RSTP - Select this param ter to set the Rapid Spanning Tree Proe
MSTP - Select this parameter to set the Multiple Spann
Hello Time: (1 - 10 sec)
The Hello Time can be set from 1 to 10 seconds. This is the interval between two
transmissions of BPDU packets sent by the Root Bridge to tell all other switches
that it is indeed the Root Bridge. This field will only appear here when STP or
RSTP is selected for the STP Version. For MSTP, the Hello Time must be set on
a port per port basis. See the MSTP Port Information section for further details.
Max Age: (6 - 40 sec)
The Max Age may be set to ensure that old information does not endlessly
circulate through redundant paths in the network, preventing the effective
propagation of the new information. Set by the Root Bridge, this value will aid in
determining that the Switch has spanning tree configuration values consistent with
other devices on the bridged LAN. If the value ages out and a BPDU has still not
been received from the Root Bridge, the Switch will start sending its own BPDU to
all other switches for permission to become the Root Bridge. If it turns out that
your switch has the lowest Bridge Identifier, it will become the Root Bridge. The
user may choose a time between 6 and 40 seconds. The default value is 20.
Forward Delay
sec)
The can be from 4 to 30 seconds. Any port on the Switch spends
te to the for-
warding state.
: (4 - 30
Forward Delay
this time in the listening state while moving from the blocking sta
73
