DGS-3312SR Stackable Gigabit Layer 3 Switch
Max Hops (1-20)
Used to set the number of hops between devices in a spanning tree region before
the BPDU (bridge protocol data unit) packet sent by the Switch will be discarded.
until the value
reaches zero. The Switch will then discard the BDPU packet and the information
held for the port will age out. The user may set a hop count from 1 to 20. The
Each switch on the hop count will reduce the hop count by one
default is 20.
TX Hold Count (1-10)
um number of Hello packets transmitted per interval. The
co t c
Used to set the maxim
un an be specified from 1 to 10. The default is 3.
Forwarding BPDU
This fie
STP BPDU packets from other network
ld can be Enabled or Disabled. When Enabled, it allows the forwarding of
devices. The default is Enabled.
Click Apply to implement changes made.
N
c ng
the above parameters:
M
M
OTE: The Hello Time cannot be longer than the Max. Age. Otherwise, a
onfiguration error will occur. Observe the following formulas when setti
ax. Age 2 x (Forward Delay - 1 second)
ax. Age 2 x (Hello Time + 1 second)
74
