Chapter 9. System
123
Global Device Properties These settings allow you to set the default properties used
by all devices:
Occupy Timeout: Set the number of seconds for a
user's session to be inactive before the access is
released for use by another user, when using the
Occupy Access Mode. This will be the default setting for
Transmitters.
EDID Mode Selection: Extended Display Identification
Data (EDID) contains a display's basic information and is
used by the source device to utilize the best resolution
across different monitors. This will be the default setting
for Transmitters. Select how you want the source device
to acquire the display's EDID:
Default: EDID is set to the ATEN default
configuration.
Auto: Checks the EDID of all connected displays
and uses the best resolution for all displays.
Manual: Manually set the EDID configuration from
the User Station’s OSD (see Manual EDID,
page 42).
Remix: Checks the EDID of all connected displays
and the source device uses the best common
resolution for all displays.
Beeper: Check this box for the device to alert you with a
sound when its first being accessed or when a configura-
tion change is made.
Use the Sync check box for each option above to push the
setting change to the devices after you click Save.
