KE6900 / KE6940 User Manual
160
Profile Command
The Profile command allows you to connect profiles and video walls.
The formula for Profile commands is as follows:
Command + Profile + Num1 + Control + [Enter]
1. For example, to connect profile 8 and lock the OSD menu, type the
following:
profile f8 [Enter]
2. For example, to connect profile 4 with access to the OSD menu, type the
following:
profile f4 release [Enter]
3. For example, to disconnect profile 12 and return to the User Station to the
OSD menu, type the following:
profile f12 back [Enter]
The following tables show the possible values for the Profile commands:
Command Description
profile Profile command
Profile Description
f Profile ID
Num1 Description
xx Profile or Video Wall ID
xx: 1-99
Control Description
lock Connect profile, lock access to
OSD menu (default)
release Connect profile, allow access to
OSD menu
back Disconnect profile, return User
Station to OSD menu
