Aten KE6900 [150/222] Filter

KE6900 / KE6940 User Manual

136

Filter

Filter lets you narrow the log event display to ones that occurred at specific

times; ones containing specific words or strings. When you access this

function, the log filter dialog box appears at the bottom of the page:

A description of the filter items is given in the table, below:

Item Description

Time This feature lets you filter for events that occurred at specific

times, as follows:

Today: Only the events for the current day are displayed.

All: Displays all events.

Range: Select a time frame of events. After selecting Range, click

inside the From and To text box to bring up the calendar.

 From: Filters for events from a specific date and time to the

present. Click inside the From box to bring up a calendar. Set

the date and time that you want the filtering to start from. All

events from the Start date/time to the present are displayed.

 To: Filters for events from a specific date and time to a specific

date and time. Click inside the From box to bring up a calendar.

First select the From (described above).

Pattern Filters for a particular word or string. Key the word or string into

the Information text box. Only events containing that word or

string are displayed. Wildcards (? for single characters; * for

multiple characters) and the keyword or are supported. E.g., h*ds

would return hands and hoods; h?nd would return hand and hind,

but not hard; h*ds or h*ks would return hands and hooks.

Apply Click to apply the filter choices.

Reset Click this button to clear the entries in the dialog box and start with

a clean slate.

Cancel Click this button to exit the log filter function.
