KE6900 / KE6940 User Manual
32
After entering the information, click Save.
RS232 Settings Configure the serial device settings for the User Station. The
default settings are:
Baud Rate: 9600
Parity: None
Data Bits: 8 bits
Stop bits: 1 bit
Flow Control: None
Enable Media Select which type of media the User Station can stream from
Transmitters: Video, Audio, USB, and RS232.
Manager
Address
Set the IP address and Port number of the computer running
the Matrix Manager software. The default port number is 9110.
Beeper Check this box to allow the User Station to beep when
configuration changes are made to it.
USB Mode Select the type of USB device you will connect to the USB ports:
vUSB (generic USB device): Use this option to plug USB
peripherals into the USB ports. This option also allows a
keyboard and mouse with special functions to plug into the USB
ports for console use. Use this only if the special functions of the
keyboard or mouse are required but do not work when plugged
into the console ports. When the keyboard and mouse are
plugged into the USB ports, they will not work within the OSD
menus. To work within the OSD menus, the keyboard and
mouse must be plugged into the console ports.
VM (Virtual Media): Only select this option if you are plugging a
USB disk into the USB ports. This will give you the highest data
transfer speeds but will not allow other USB devices plugged
into the USB ports to work.
Secure: Check this box to encrypt USB drives plugged into the
USB ports.
