KE6900 / KE6940 User Manual
2
Features
Remote KVM console access of computers over LAN or Ethernet cable
connection
Dual console operation – control your system from both the Transmitter
and Receiver by USB keyboard, monitor, and mouse
RS-232 serial ports
allows you to connect to a serial terminal for
configuration, and serial devices such as touchscreens and barcode
scanners
1
Superior video quality – up to 1920 x 1200 @ 60 Hz; 24-bit color depth
Supports standard VGA resolutions from 640 x 480 to 1920 x 1200 at
60Hz
OSD (On Screen Display) on the Receiver configures both units
Supports Matrix Manager Web GUI
administration
2
Matrix Manager Lite provides web GUI support for smaller installations
3
Remote login security
DVI digital and analog monitor support
Built-in ESD protection and surge protection
Supports stereo speakers and microphone
Auto-MDIX - automatically detects cable type
Supports widescreen formats
Supports High-Quality Video streaming
Virtual Media Support
Hot pluggable
Rack Mountable
Upgradeable firmware
Note: 1. RS-232 serial ports support Tx/Rx/CTS/RTS/DTR/DSR signals only.
2. The Matrix Manager web GUI can be updated from the CCKM page
on our website: www.aten.com. To obtain a license for the full
version of the software please contact your ATEN dealer.
3. The Matrix Manager Lite is a web GUI that supports up to 8 KE
devices and can be downloaded for free after registering your product
on the ATEN eService website (http://eservice.aten.com).
