Aten KE6900 [160/222] To use the original system set preferences click restore defaults

KE6900 / KE6940 User Manual

146

When you have made your choices, Click Save.

To use the original system set preferences, click Restore Defaults.

Password This section allows you to change the user’s password:

1. Key in your old password in the Old password field.

2. Key in your new password in the New password field.

3. Key in your new password again in the Confirm password

field.

Item Description
