KE6900 / KE6940 User Manual

Invoking the OSD

The On Screen Display (OSD) is a keyboard/mouse-driven application on the

receiver used to configure the transmitter and receiver settings. Once the

receiver has discovered the transmitter over a network* or direct Ethernet cable

connection, you can use the OSD on the receiver to configure the transmitter’s

settings.

To invoke the OSD, press the OSD pushbutton on the front of the receiver, or

from the keyboard tap the Scroll Lock key twice. The OSD main page will

appear (see OSD Interface, page 29).

To exit the OSD, press [Esc] on the keyboard; click Logout; tap the Scroll

Lock key twice; or return to the OSD main page and press the OSD pushbutton

on the front of the receiver. The OSD disappears and the computer desktop

screen or the System Login prompt is displayed.

Note: 1. For the Receiver to discover the Transmitter over a network, both

must be on the same subnet of the LAN.

2. To change the OSD hotkeys see page 39.

3. If the keyboard/mouse won’t work when the OSD is invoked, see

USB Mode, page 74.

Microphone Hotkey

You can switch microphone access between User Stations with a hotkey:

1. Press and hold down [Num Lock].

2. Press and release [-].

3. Release [Num Lock].

4. Press 1.

Press the Esc key to cancel.

Touch Screen Calibration

If you’re using a touch screen monitor and the OSD appears off center, you can

use the blinking

+ at each corner to adjust the position of the OSD.
