KE6900 / KE6940 User Manual
164
Reset Command
The Reset command allows you to reset a device back to the default factory
settings. Reset includes resetting the devices IP address.
The formula for the Reset command is as follows:
Command + Address + Number + [Enter]
1. For example, to reset device (192.168.0.95), type the following:
reset a192.168.0.95 [Enter]
2. For example, to reset the User Station, type the following:
reset [Enter]
The following tables show the possible values for the Reset command:
The following table lists the available Reset commands:
Note: 1. Each command string can be separated with a space.
2. Skip the Address and Number command strings to reset the local
User Station.
Command Description
reset Reset command
Address Description
a Address command
Number Description
xx Address number
xx: User Station ID or IP address
Command Address Num Enter Description
reset a xx [Enter] Reset address xx back to the
factory default settings
xx: Device ID or IP Address
reset [Enter] Resets the User Station
settings
