Appendix
187
Specifications
Function KE6900T KE6940T
Connectors Console
Ports
Keyboard 1 x USB Type A Female (White)
Video 1 x DVI-I Female
(White)
2 x DVI-I Female
(White)
Mouse 1 x USB Type A Female (White)
Speaker 1 x Mini Stereo Jack Female (Green)
Mic. 1 x Mini Stereo Jack Female (Pink)
RS-232 1 x DB-9 Male (Black)
KVM
Ports
KB / Mouse USB Type B Female (White)
Speaker 1 x Mini Stereo Jack (Green)
Mic. 1 x Mini Stereo Jack (Pink)
Video 1 x DVI-I Female
(White)
2 x DVI-I Female
(White)
RS-232 1 x DB-9 Female (Black)
Power 1 x DC Jack (Black)
LAN 1 x RJ-45 Female (Black)
Switches Console Selection /
Config
1 x Slide switch (Black)
(Auto, Local, Config)
Reset 1 x Semi-recessed Pushbutton
LEDs LAN 1 (Green / Orange)
Power 1 x Blue
Local 1 x Green
Remote 1 x Green
Emulation Keyboard / Mouse USB
Power Consumption DC 5V DC 5V
Video Up to 1920 x 1200
Environment Operating Temp. 0–50ºC
Storage Temp -20–60ºC
Humidity 0–95% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 1.13 kg 1.15 kg
Dimensions
(L x W x H)
21.50 x 16.30 x 4.60 cm
