KE6900 / KE6940 User Manual
162
EDID Command
Extended Display Identification Data (EDID) is a data that contains a display's
basic information and is used to communicate with the video source. The EDID
commands allow you to change the EDID setting of a Transmitter.
The formula for the EDID command is as follows:
Command + Address + Number + Control + [Enter]
1. For example, if you want to configure device (192.168.0.3) to use the
remix EDID mode, type the following:
edid a192.168.0.3 remix [Enter]
The following tables show the possible values for the EDID commands:
The following table lists the available EDID commands:
Command Description
edid EDID command
Address Description
a Address command
Number Description
xx Address number
xx: User Station ID or IP address
Control Description
auto Checks the EDID of all connected
displays and uses the best resolution for
all displays.
remix Checks the EDID of all connected
displays and the source device uses the
best common resolution for all displays.
default Implements ATEN’s default EDID.
(default)
manual Manually set the EDID configuration from
the User Station’s OSD (see Manual
EDID, page 42).
Command Address Number Control Enter Description
edid a xx auto [Enter] Set EDID of address xx to auto.
xx: Device ID or IP Address
