Chapter 13. RS-232 Commands

167

Note: 1. Each command string can be separated with a space.

2. The Baud Rate value is required but Parity, Data Bit and Stop Bit

can be skipped and their setting will not change.

3. Skip the Address and Number command strings to configure the

local device settings.

baud 9600 Set local device

baud rate to

9600

baud 19200 Set local device

baud rate to

19200

baud 38400 Set local device

baud rate to

38400

baud 115200 Set local device

baud rate to

115200

Com

mand

Address

Num

Baud

Rate

Parity

Data

Bit

Stop

Bit

Flow

Control

Description
