Chapter 2. Hardware Setup

Point-to-Point Installation 1 of 2

Note: The diagram above shows the KE6900T and KE6900R. The KE6940

installation is the same except that an additional DVI monitor can be

connected at each end for a dual-view display setup.

KE6900R

KE6900T

Cat 5e/6 cable
