Aten KE6900 [32/222] Local pc

KE6900 / KE6940 User Manual

Point-to-Point Installation 2 of 2

Note: The serial port on the Transmitter (shown above) connects to the

computer; the serial port on the Receiver (not shown) connects to a

serial device (optional).

USB KVM

cable

Local PC

KE6900T
